Precision Flight Modular Flight Deck with GNS430 and X-Plane 9 - Manual (Page 13)

Set Up Guide For MFD with G430 and X-Plane 9 Page 13
E. Enable the Instructor’s Station
19. In the Local Region window, enable the IOS check box as shown below.
20. Once back to the instructor’s station, click on Quit All.
F. Enable communication from Master PC to Visual PC.
Changing the IP Address of the Master Machine
21. Open Network Connections by clicking the Start button, click on the Control Panel
22. Clicking Network and Sharing Center.
23. Click on the Change
Adapter Settings on the left
menu.
