Medal Sports YSLSUIG3003/AC25800 - Manual (Page 10)

Assembly Instructions
Step 5:
10. Attach the Goal Box Supports (#10) to the End
Aprons (#2) using four Screws (#40) per Goal
Box Support.
11. Attach two Plastic Brackets (#26) to each End
Apron using two Screws (#39) per Bracket.
9. Lower the Playfield (#3) onto the Side Aprons
(#1) and Goal End Boards (#5) as shown.Do not
fasten playfield to the frame at this time.
Step 6:
9
10
26
39
40
2
3
1
1
5
5
FIG.5
FIG.6
