Outdoor Hot Tub Kit
Art. no: 9999-000-9999
1 Stove of aluminium
1 Stainless grating
1 Stainless baffle plate
1 Cover with wooden handle
2 Galvanized chimney flues
1 Galvanized chimney top
1 Stainless outlet
2 Rubber pipe connection
1 Plastic pipe with bend
1 Straight plastic pipe (overflow outlet)
1 Hose clamp
2 Hoops of aluzink, L:6.7 m
4 Bolted joints of lacquered steel
4 Screw plates for the bolted joints
4 M12 Threaded bars
8 M12 nuts with washers
16 M8 Flathead screws with washers and nuts
10 Fleur-de-lis of lacquered steel
6 Bench brackets of galvanized steel
Wood needed (fittings not included):
Side boards: approx. 45x95 mm, 90 linear metres for a hot tub of D:2
m.
Tongued and grooved bottom boards: 25-40 mm, approx. 4 m
2
.
Bottom joists: 8 linear metres, approx. 50x120 mm.
Larch, spruce or oak is preferable for the bottom and side boards.
Boards: 10 m 22x120 mm of which 7 linear metres should be of rot
resistant wood, e.g. larch or pine heartwood.
A couple of sturdy planks that will be used as work surface
Some boards for building the work station at the compound saw, and
for the compass (see below)
Material
