Award BIOS SETUP
3-16
•
Onboard FDC Controller: The default value is Enabled.
Enabled: Enable the Onboard SMC CHIP's floppy drive interface controller.
Disabled: Disable the Onboard SMC CHIP's floppy drive interface control-
ler.
•
Onboard Serial Port 1: This field allows the user to select the serial port.
The default value is Auto.
AUTO:
Enable Onboard Serial port 1 and address is Auto adjusted
COM1:
Enable Onboard Serial port 1 and address is 3F8H/IRQ4.
COM2:
Enable Onboard Serial port 1 and address is 2F8H/IRQ3.
COM3:
Enable Onboard Serial port 1 and address is 3E8H/IRQ4.
COM4:
Enable Onboard Serial port 1 and address is 2E8H/IRQ3.
Disabled: Disable Onboard SMC CHIP's Serial port 1.
•
Onboard UART 2: This field allows the user to sellect the serial port. The
default value is Auto.
AUTO:
Enable Onboard Serial port 2 and address is Auto adjusted
COM1:
Enable Onboard Serial port 2 and address is 3F8H/IRQ4.
COM2:
Enable Onboard Serial port 2 and address is 2F8H/IRQ3.
COM3:
Enable Onboard Serial port 2 and address is 3E8H/IRQ4.
COM4:
Enable Onboard Serial port 2 and address is 2E8H/IRQ3.
Disabled: Disable Onboard SMC CHIP's Serial port 2.
•
Onboard UART 2 Mode: The default value is standard. This field allows the
user to select the COM2 port that can support a serial Infrared Interface.
Standard: Support a Serial Infrared Interface IrDA.
IrDA:
Support a Serial Infrared Interface format.
ASKIR:
Support a Sharp Serial Infrared Interface format.
•
Onboard Parallel port: This field allows the user to sellect the LPT port.
The default value is 378H/IRQ7.
378H:
Enable Onboard LPT port and address is 378H and IRQ7
278H:
Enable Onboard LPT port and address is 278H and IRQ5.
3BCH:
Enable Onboard LPT port and address is 3BCH and IRQ7.
Disabled: Disable Onboard SMC CHIP's LPT port.
•
Parallel Port Mode: This field allows the user to sellect the parallel port
mode. The default value is ECP+EPP.
Normal:
Standard mode. IBM PC/AT Compatible bidirectional
parallel port.
EPP:
Enhanced Parallel Port mode.
ECP:
Extended Capabilities Port mode.
EPP+ECP:
ECP Mode & EPP Mode.
