2-2 Connectors and Jumpers
This section describes all of the connectors and jumpers built into the
motherboard. The jumpers match Figure 2-1 on page 2-2
Speaker - connect to the system's speaker for beeping
1. Speaker 3. GND
2. N/C 4. GND
Reset - Closed to restart system.
Turbo LED indicator - LED ON when higher speed is
selected
Sleep/Resume switch : Closed to enter sleep mode, a key-
stroke or mouse movement will instantly "wake up".
Power Saving LED indicator - LED ON when system is in
any saving mode
IDE LED indicator - LED ON when Onboard PCI IDE Hard
disks activate
KeyLock - Keyboard lock switch & Power LED connector
1. Power LED(+) 4. Keylock
2. N/C 5. GND
3. GND
J9
Power On/Off 1
1
+
+
+
J16
Installation 2-3
+
