Operating Your
Ceiling Fan
IMPORTANT
Fan installation must be completed,
including the installation of the fan
blades, before testing of the remote
control.
Your Fan/Light Wall Control (Figure 19)
has full control of your fan and light.
However, airflow direction is controlled by
a pull chain on the light fitter switch.
1. Restore electrical power to the outlet
box by turning the electricity on at the
service panel.
NOTE: Make sure that the ON/OFF slide
switch on the Fan/Light Wall Control is
in the ON position.
2. To set the desired fan speed, press the
HI, MED, or LOW buttons to operate
your fan on high, medium, or low speed
(Figure 19).
3. To turn your fan off, press the OFF
button.
4. To set the level of housing light
brightness, press and hold the LIGHT
button. The light brightness will
continue to increase then decrease
while the button is held down. When
the light is at the desired brightness,
release the button.
5. To turn the housing lights on and off,
press and release the LIGHT button.
The light will turn on at the light level
previously set (see step 4).
6. If airflow is desired in the opposite
direction, turn the fan off and wait for
the blades to stop turning. Turn the
lower glass counterclockwise and
remove the glass from the light fitter
(Figure 12). Remove the pull chain
from the clip on the light fitter and pull
on the pendant until the reversing
switch clicks. Replace the pull chain in
the clip, then replace the lower glass on
the light fitter, and turn the glass
clockwise until the glass stops turning.
Turn the fan on again; the blades will
turn in the opposite direction and
reverse the airflow.
EMERSON ®
HI
MED
LOW
FAN OFF
LIGHT
ON OFF
Figure 19
