Handling and operation
GB
MT
50 UPA 500 A1
Wall mounting
DANGER
When drilling the holes ensure that any electric cables or ►
other installations in the wall, such as water pipes, are not
damaged.
TAKE NOTE
The supplied plugs are only suitable for a mounting on con- ►
crete or stone. Before starting the installation, please check
your installation location carefully for its suitability for the
plugs. If in doubt, call a professional.
Attach the Parking Lamp ♦ on the garage wall at the level of
the windshield of your vehicle. For this, mark two boreholes with
a vertical spacing of 130 mm.
Attach the ultrasonic sensor on the garage wall at the level of ♦
the bumper of your vehicle. For this, mark two boreholes with a
vertical spacing of 45 mm.
Now bore, using an electric or hand drill fi tted with a 6 mm ♦
drill, the four holes to a minimum depth of 30 mm.
Insert the plugs into the holes and screw the screws in. Leave ♦
the screw heads protruding a little.
Now hang the Parking Lamp
♦ and the ultrasonic sensor 7
on the screws.
NOTICE
Alternatively, you can also use the supplied hook and loop ►
pads for mounting the Parking Lamp and the ultrasonic
sensor 7 .
