Relay Control Modules • Specifications, Part #s, Dimensions
Specifications, Part Numbers, Accessories, cont’d
Dimensions
The following diagrams have been reduced to fit on the page.
All dimensions are given in inches. The symbol “ø“ indicates a
diameter.
RCM dimensions
A-4
.160
.320
.182
.363
DETAIL A
RCM-SC
RCM-SCLT
0.000
0.000
0.250 0.600 3.250
0.195
0.345
0.695
1.045
1.195
1.390 +.000
-.015
3.500
2.900
Ø.160 +.000/
-.010 max. extrusion around
stud on far side,
Ø.112 +.003/
-.000 thru (4 places).
PEM insert FHS-440-6 or equiv.
Insert from near side. (4 req'd)
Ø.166 +.003/
-.000 thru (2 places).
PEM insert BSOS-440-16 or
equiv. Insert from near side.
DETAIL A
(5 PLCS)
R.050
(4 PLCS)
0.000
0.000
0.250 0.600 0.714
0.714
1.232 2.786
2.786
3.250
0.195
0.345
0.695
1.045
1.195
1.390 +.000
-.015
3.500
2.900
Ø.160 +.000/
-.010 max. extrusion around
stud on far side,
Ø.112 +.003/
-.000 thru (4 places).
PEM insert FHS-440-6 or equiv.
Insert from near side. (4 req'd)
Ø.166
+.003/
-.000
thru (2 places).
PEM insert BSOS-440-16 or
equiv. Insert from near side.
DETAIL A
(5 PLCS)
R.050
(4 PLCS)
1.750
