Exmark Lazer ZXP User Manual

Page 9

52” MOWER DECK FMD524

- 7 -

Ref.

No.

Qty.

Part No.

Description

Req'd.

Ref.

No.

Qty.

Part No.

Description

Req'd.

103-1895

Support,deck

103-2324-01w/bsgs&decals

3234-11 Screw, whizlock 3/8-16 x 1 ....... 2

323-6 Capscrew, 3/8-16 x 1 ............... 2

3296-39 Nut, nylock 3/8-16..................... 20

98-5975 Washer, disc spring 3/8 ........... 19

3256-4 Washer, 3/8 .............................. 3

3290-357 Nut, whizlock 3/8-16 ................. 25

1-513034 Bearing, pivot............................ 4

1-806009 Hairpin, .177............................. 4

1-602604 Idler arm assy w/bearings......... 1

1-323539 Spacer...................................... 2

1-602591-03 Arm, deck idler ......................... 1

1-634619 Housing w/Brg,Spcr &Ring....... 3

1-603384 Bushing, idler pivot ................... 2

1-413425 Spacer...................................... 2

1-602865 Idler arm, w/ brngs deck drive... 1

1-513336 Bushing, deck support.............. 2

1-602867-03 Arm, deck drive idler................. 1

32120-33 Ring, retaining (external) .......... 2

302-40 Zerk, 1/4-28 (90°) ..................... 2

1-373034 Washer, pivot ........................... 6

323-11 Capscrew, 3/8-16 x 2-1/4.......... 2

1-543509 Bearing cone, tapered roller..... 4

1-413525 Link, rear deck support ............. 2

1-543508 Bearing cup, tapered roller....... 4

1-613204 Balljoint ..................................... 2

103-1891-01 Fork, caster .............................. 2

1-603299 Roller, anti scalp ....................... 6

325-20 Capscrew, 1/2-13 x 6 ............... 2

98-5961 Capscrew, 3/8-16 x 4 Gr8......... 6

103-2355 Spacer, front caster.................. 2

1-603602 Bushing, roller........................... 6

103-1687 Tire & Wheel Asm .................... 2

1-603620-01 Bracket, spring anchor ............. 1

1-513032 Tire, 11 x 4-5 4 ply.................... 2

1-800805 Capscrew, 3/8-16 x 3 ½ Gr8..... 2

103-2274 Wheel....................................... 2

1-603414 Spring, extension...................... 1

1-633584 Bearing cup .............................. 4

1-602913-01 Baffle ........................................ 1

103-2333 Cover, w/ decal......................... 1

65▲ 103-2328

Housing, cutter complete (center)

.. 1

103-2318-01 Cover, deck .............................. 2

103-1140

Housing, cutter complete (outer)

.... 2

103-2329 Belt, blade drive ....................... 1

3256-24 Washer, 3/8 SAE Flat............... 5

323-23 Capscrew, 3/8-16 x 4.5 ............. 1

1-603001 Rod, deck support .................... 2

3219-6 Nut, 5/8-18 UNF ....................... 3

1-806332 Roll pin, 1/4 x 1-1/2................... 2

1-513208 Spring, disk .............................. 3

1-613098 Idler........................................... 1

1-633701 Sheave, blade drive.................. 3

1-603805 Idler........................................... 1

1-513016 Bearing .................................... 6

1-513791 Bushing..................................... 1

1-323532 Housing, bearing ...................... 3

1-633988 Spacer ...................................... 1

1-323528 Spacer, bearing........................ 3

1-603050 Spacer ...................................... 4

1-633573 Guard, dust .............................. 3

323-9 Capscrew, 3/8-16 x 1 3/4.......... 2

32120-8 Snap ring.................................. 3

75❖ 1-414521 Link Assy .................................. 2

10-8040 Key, square .............................. 4

1-323533 Spacer,Shv/Brg......................... 3

103-2326 Spindle, outer blade (short)...... 2

103-0865 Washer,Blade bolt hvy.............. 3

103-2219 Spindle, center blade (long) ..... 1

103-1331 Guard,bearing top..................... 3

1-633482 Blade, notched air foil............... 3

103-0063 Seal, caster............................... 4

1-613251 Blade, solid air foil .................... 3

3296-51 Nut, nyloc ¾-10 ........................ 2

1-633485 Blade, low lift ............................ 3

1-543513 Cap, grease .............................. 2

1-633484 Blade, mulching........................ 3

1-323385 Knob, 3 prong ........................... 5

103-1578 Blade, bahia ............................. 3

1-323417 Washer, belt cover mounting.... 5

3219-3 Nut, hex 3/8-24......................... 2

1-811010 Plug .......................................... 2

103-0862 Capscrew, 5/8-18x2¾ Gr8 ....... 3

1-543511 Seal, grease ............................. 2

323-8 Capscrew, 3/8-16 x 1 ½ .......... 18

1-633581 Spacer, bearing ........................ 4

103-2335 Deck, 103-2321-01

w/ rods & baffle

1-633508 Washer, spring disk.................. 6

103-2348-01 Chute, Discharge ..................... 1

1-633585 Bearing, cone ........................... 4

322-5 Capscrew, 5/16-18 x 1 ............. 2

1-800017 Bolt, Tap 5/16-18 x 3 ¼ ........... 2

3296-29 Nut, nylock 5/16-18 .................. 8

3296-45 Nut, nyloc ½-13 thin.................. 2

322-2 Capscrew, 5/16-18 x 5/8 .......... 5

3256-3 Washer, 5/16 flat ...................... 6

1-303516 Pulley, V-Idler........................... 2

323-12 Capscrew, 3/8-16 x 2 ½ ........... 2

32128-20 Nut, whizlock 5/16-18 ............... 8

322-3 Capscrew, 5/16-18 x 3/4........... 1

1-603504 Spacer, tube............................. 1

103-2495 Caster Wheel Assy. ................. 2

1-603581 Sheave, mower drive................ 1

323-7 Capscrew,3/8-16 x 1 ¼ . .......... 8

1-603413 Spring, extension...................... 1

103-2327 Complete deck assembly . ...... 1

1-603497 Pulley, idler............................... 1

Exmark red touch up spray paint - P/N 1-850337

n Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK524.

❖ Link assembly must be assembled to 6.89” (or approx. 6 7/8”) length between center of ball joint & center of furthest hole.
See diagram on next page.
▲ Outer cutter housing complete includes sheave, washer & nut.

Center

cutter housing complete includes sheaves, washer, spacer & nut.

Note: Kit 103-2250 is required when installing FMD524 or 604 to Turf Ranger unit Serial No. 319,999 & below.
