Exmark Lazer ZXP User Manual

Page 11

60” MOWER DECK FMD604

- 9 -

Ref.

No.

Qty.

Part No.

Description

Req'd.

Ref.

No.

Qty.

Part No.

Description

Req'd.

103-1896 Support,deck 103-2249-01

1-603497 Pulley, idler.. ................................. 1

w/bsgs&decals…………………….. 1

3234-11 Screw, whizlock 3/8-16 x 1............ 2

323-6 Capscrew, 3/8-16 x 1 ................... 2

3296-39 Nut, nylock 3/8-16 ......................... 20

98-5975 Washer, disc spring 3/8................ 19

3256-4 Washer, 3/8 .................................. 3

3290-357 Nut, whizlock 3/8-16 ..................... 25

1-513034 Bearing, pivot ................................ 4

1-806009 Hairpin, .177 ................................. 4

1-602604 Idler arm assy w/bearings ............. 1

1-323539 Spacer.......................................... 2

1-602591-03 Arm, deck idler.............................. 1

1-634619 Housing w/Brg,Spcr &Ring ........... 3

1-603384 Bushing, idler pivot........................ 2

1-413425 Spacer.......................................... 2

1-602865 Idler arm, w/ brngs deck drive ....... 1

1-513336 Bushing, deck support .................. 2

1-602867-03 Arm, deck drive idler ..................... 1

32120-33 Ring, retaining (external) .............. 2

302-40 Zerk, 1/4-28 (90°).......................... 2

1-373034 Washer, pivot ............................... 6

323-11 Capscrew, 3/8-16 x 2-1/4 .............. 2

1-543509 Bearing cone, tapered roller ......... 4

1-413525 Link, rear deck support.................. 2

1-543508 Bearing cup, tapered roller ........... 4

1-613204 Balljoint ......................................... 2

103-1891-01 Fork, caster .................................. 2

1-603299 Roller, anti scalp ........................... 6

325-20 Capscrew, 1/2-13 x 6.................... 2

98-5961 Capscrew, 3/8-16 x 4 Gr8 ............. 6

103-2355 Spacer, front caster ...................... 2

1-603602 Bushing, roller ............................... 6

103-1687 Tire & Wheel Asm ........................ 2

1-603620-01 Bracket, spring anchor .................. 1

1-513032 Tire, 11 x 4-5 4 ply........................ 2

1-800805 Capscrew, 3/8-16 x 3 ½ Gr8 ......... 2

103-2274 Wheel........................................... 2

1-603414 Spring, extension .......................... 1

1-633584 Bearing cup .................................. 4

1-602913-01 Baffle ............................................ 1

103-2276 Cover, w/ decal............................. 1

65▲ 103-2314 Housing, cutter complete (center) . 1

103-2271-01 Cover, deck RH ............................ 1

103-1140 Housing, cutter complete (outer) ... 2

103-2272-01 Cover, deck LH............................. 1

3256-24 Washer, 3/8 SAE Flat ................... 5

1-633173 Belt, blade drive............................ 1

1-603001 Rod, deck support......................... 2

323-23 Capscrew, 3/8-16 x 4.5................. 1

1-806332 Roll pin, 1/4 x 1-1/2 ....................... 2

3219-6 Nut, 5/8-18 UNF ........................... 3

1-613098 Idler............................................... 1

1-513208 Spring, disk .................................. 3

1-603805 Idler............................................... 1

1-633701 Sheave, blade drive...................... 3

1-513791 Bushing......................................... 1

1-513016 Bearing ........................................ 6

1-633988 Spacer .......................................... 1

1-323532 Housing, bearing .......................... 3

1-603050 Spacer .......................................... 4

1-323528 Spacer, bearing ............................ 3

323-9 Capscrew, 3/8-16 x 1 3/4 .............. 2

1-633573 Guard, dust................................... 3

75❖ 1-414521 Link Assy ...................................... 2

32120-8 Snap ring...................................... 3

1-323533 Spacer,Shv/Brg............................. 3

10-8040 Key, square .................................. 4

103-0865 Washer,Blade bolt hvy .................. 3

103-2326 Spindle, outer blade (short) .......... 2

103-1331 Guard,bearing top ......................... 3

103-2219 Spindle, center blade (long).......... 1

103-0063 Seal, caster................................... 4

1-633483 Blade, notched air foil ................... 3

3296-51 Nut, nyloc ¾-10............................. 2

1-613250 Blade, solid air foil ........................ 3

1-543513 Cap, grease .................................. 2

1-613111 Blade, low lift ................................ 3

1-323385 Knob, 3 prong ............................... 5

103-0301 Blade, mulching............................ 3

1-323417 Washer, belt cover mounting ........ 5

103-1580 Blade, bahia ................................. 3

1-811010 Plug............................................... 2

3219-3 Nut, hex 3/8-24............................. 2

1-543511 Seal, grease.................................. 2

103-0862 Capscrew, 5/8-18x2¾ Gr8............ 3

1-633581 Spacer, bearing............................. 4

323-8 Capscrew, 3/8-16 x 1 ½ ............... 18

1-633508 Washer, spring disk ...................... 6

103-2278 Deck, 103-2267-01 w/ rods & baffle 1

1-633585 Bearing, cone................................ 4

103-2349-01 Chute, Discharge.......................... 1

1-800017 Bolt, Tap 5/16-18 x 3 ¼ ................ 2

322-5 Capscrew, 5/16-18 x 1.................. 2

3296-45 Nut, nyloc ½-13 thin ...................... 2

3296-29 Nut, nylock 5/16-18 ...................... 8

3256-3 Washer, 5/16 flat........................... 6

322-2 Capscrew, 5/16-18 x 5/8............... 5

323-12 Capscrew, 3/8-16 x 2 ½ ............... 2

1-303516 Pulley, V-Idler ............................... 2

322-3 Capscrew, 5/16-18 x 3/4 ............... 1

32128-20 Nut, whizlock 5/16-18 ................... 8

103-2495 Caster Wheel Assy. ..................... 2

1-603504 Spacer, tube ................................. 1

323-7 Capscrew, 3/8-16 x 1 ¼ .............. 8

103-2270 Sheave, mower drive.................... 1

103-2279 Complete deck assembly ............ 1

1-603413 Spring, extension.......................... 1

Exmark red touch up spray paint - P/N 1-850337

n Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK604.

❖ Link assembly must be assembled to 6.89” (or approx. 6 7/8”) length between center of ball joint & center of furthest hole.
See diagram on next page.

▲ Outer cutter housing complete includes sheave, washer & nut.
Center

cutter housing complete includes sheaves, washer, spacer & nut.

Note: Kit 103-2250 is required when installing FMD524 or FMD604 deck to Turf Ranger unit Serial No. 319,999 & below.
