Exmark Lazer ZXP - Manual (Page 19)

RIDER FRAME and STEERING
- 17 -
Ref.
No. Qty.
.Part No. Description Req'd.
Ref.
No. Qty.
Part No. Description Req'd.
1 1-542920-01 Frame, rider ....................... 1 30ƒ 1-542194-01 Bracket, pivot(LH) .............. 1
2 1-543509 Bearing cone, tapered roller 4 31 322-5 Capscrew, 5/16-18 x 1 ....... 5
3 1-543511 Seal, grease........................ 3 32 1-543679 Tire, 18 x 7.50-8 ................. 1
4 302-19 Zerk, 1/4-28 (straight) ......... 3 33 321-3 Capscrew, 1/4-20 x 5/8 ...... 4
5 3256-28 Washer, 3/4sae .................. 2 34 1-806332 Rollpin, 1/4 x 1-1/2 ............. 2
6 3272-17 Pin, cotter 5/32 x 1.25......... 1 35 3256-22 Washer, 1/4........................ 4
7 32136-5 Nut, slotted 3/4-16 .............. 1 36 1-513588 Bearing, DU........................ 2
8 1-543513 Cap, grease ........................ 1 37 1-543172-01 Shaft, foot pedal................. 1
9 1-543296 Grommet............................. 1 38 1-542140-01 Lever, foot pedal ................ 1
10 3256-3 Washer, 5/16 ...................... 2 39 1-543159 Pad, rider anti-skid (R) ....... 1
11 323-7 Capscrew, 3/8-16 x 1-1/4 ... 2 40ƒ 1-543158 Pad, rider anti-skid (L)........ 1
12 98-5975 Washer, 3/8 disc spring...... 2 41 1-552025 Shaft, steering .................... 1
13 3290-357 Nut, flange 3/8-16 ............... 10 42 1-543573 Link, connector #40............ 4
14 1-303007 Washer, 6" caster pivot ...... 4 43 1-543579 Eyebolt, 5/16-18 ................. 2
15 1-552023-03 Handle bar.......................... 1 44 1-543885 Chain, #40-29 Pitch............ 1
16 1-303097 Grip, handle bar .................. 2 45 1-543886 Chain, #40-33 Pitch............ 1
17 1-553063-01 Console .............................. 1 46 1-542870-01 Link .................................... 2
18 1-543482-01 Cover, console ................... 1 47 3218-2 Nut, jam 5/16-18................. 4
19 1-542728-03 Steering post ...................... 1 48 323-6 Capscrew, 3/8-16 x 1 ......... 6
20 32104-60 Screw, 10-24 x 1/2.............. 4 49 1-553007-01 Stop, actuator .................... 1
21 323-4 Capscrew, 3/8-16 x 3/4....... 4 50 1-542872-01 Mount, steering wheel........ 1
22 1-303199 Bushing, 6" caster flange.... 4 51 1-803042 Nut, torque 5/8-11 .............. 1
23 1-303200 Sleeve, 6" caster................. 2 52 1-800346 Capscrew, 5/8-11 x 10-1/2 . 1
24 1-806331 Roll Pin, 1/4 x 1-1/4 ............ 2 53 1-543552 Bushing, wheel ................... 1
25 1-542183-01 Pedal, foot .......................... 1 54 1-543556 Spacer, wheel (short) ......... 2
26 1-543161 Pad, reverse control pedal.. 1 55 1-543508 Bearing cup ........................ 4
27 1-543160 Pad, forward control pedal.. 1 56 1-543674 Rim ..................................... 1
28 32128-20 Nut, whizlock 5/16-18 ......... 9 57 1-543397 Tire/whl assy, 18.0 x 7.50-8 1
29 1-542196-01 Bracket, pivot (RH)............. 1 58 1-803055 U-clip, #10-24 ..................... 4
ƒ Not Illustrated.
Exmark red touch up spray paint - P/N 1-850337
Exmark black touch up spray paint - Gloss black
