52” MOWER DECK FMD523
- 3 -
Ref.
No. Qty.
Part No. Description Req'd.
Ref.
No. Qty.
Part No. Description Req'd.
1 1-604960 Support,deck 1-612092-01 w/bshgs 39 323-7 Capscrew,3/8-16 x 1 ¼..................... 18
&decals……………………………….. 1 40 1-612155 Deck,1-612287-01 w/decals,rods&baffle 1
2 323-6 Capscrew, 3/8-16 x 1 ....................... 12 41 1-602571-01 Chute, discharge .............................. 1
3 ² 98-5975 Washer, disc spring 3/8................... 19 42 322-5 Capscrew, 5/16-18 x 1...................... 2
4 ² 3290-357 Nut, whizlock 3/8-16 ........................ 33 43 3296-29 Nut, nylock 5/16-18 .......................... 2
5 1-806009 Hairpin, .177.................................... 4 44 322-2 Capscrew, 5/16-18 x 5/8................... 6
6 1-323539 Spacer, blade driver ........................ 2 45 1-303516 Pulley, V-Idler .................................. 2
7 1-634619 Housing w/brg,spacer&ring.............. 2 46 32128-20 Nut, whizlock 5/16-18....................... 6
8 1-413425 Spacer............................................. 2 47 1-603504 Spacer, tube .................................... 1
9 1-513336 Bushing, deck support..................... 2 48 1-603581 Sheave, mower drive ....................... 1
10 32120-33 Ring, retaining (external) ................. 2 49 1-603413 Spring, extension ............................. 1
11 3253-5 Washer,lock 3/8hvy spring............... 2 50 1-603497 Pulley, idler ...................................... 1
12 ² 1-373034 Washer, pivot .................................. 12 51 3239-11 Screw, whizlock 3/8-16 x 1............... 2
13 302-52 Zerk, 1/8 NPT (straight) ................... 2 52 3296-39 Nut, nylock 3/8-16............................ 20
14 1-303514 Bearing, flange thrust ...................... 4 53 3256-4 Washer, 3/8 ..................................... 3
15 1-522143-01 Fork, caster...................................... 2 54 1-513034 Bearing, pivot................................... 4
16 325-20 Capscrew, 1/2-13 x 6 ....................... 2 55 1-602604 Idler arm assy w/bearings ................ 1
17 3253-7 Washer, lock 1/2.............................. 2 1-602591-03 Arm, deck idler ................................. 1
18 3217-9 Nut, 1/2-13 ...................................... 2 56 1-603384 Bushing, idler pivot ........................... 2
19 1-513547 Spacer, front caster (pneumatic) ..... 2 57 1-602865 Idler arm, w/bearings deck drive…. 1
■ 103-2169 Spacer, front caster (semi- 1-602867-03 Arm, deck drive idler......................... 1
pneumatic)........................................ 2 58 302-40 Zerk, 1/4-28 (90°) ............................. 2
20★ 103-1224 Tire/wheel asm(semi-pneumatic)..... 2 59 323-11 Capscrew, 3/8-16 x 2-1/4 ................. 4
★ 1-513648 Tire/wheel asm (pneumatic) ............ 2 60 1-413525 Link, rear deck support .................... 2
1-513809 Roller Bearing (all)........................... 2 61 1-613204 Balljoint............................................ 2
1-513810 Bushing (pneumatic) ....................... 4 62 1-603299 Roller, anti scalp .............................. 6
m 103-2170 Bushing (semi-pneumatic)............... 4 63 98-5961 Capscrew, 3/8-16 x 4 Gr8 ................ 6
1-513807 Wheel & Hub (pneumatic) ............... 2 64 1-603602 Bushing, roller ................................. 6
1-513808 Tire 9 x 3.50-4 4-ply (pneumatic)....... 2 65 1-603620-01 Bracket, spring anchor..................... 1
21 1-544835 Cover w/decal.................................. 1 66 1-800805 Capscrew, 3/8-16x3 1/2 Gr8 ............... 2
22 1-602545-01 Cover, deck...................................... 2 67 1-603414 Spring, extension ............................ 1
23 1-603576 Belt, blade drive ............................... 1 68 1-543678 Wingnut, nylock .............................. 4
24 ²◆ 323-16 Capscrew, 3/8-16 x 4 ....................... 1 69 1-602913-01 Baffle............................................... 1
∆ 323-23 Capscrew, 3/8-16 x 4 1/2 ................. 1 70▲ 103-1185 Housing, cutter complete cntr)……… 1
25 3219-6 Nut, 5/8-18 UNF............................... 3 103-1187 Housing, cutter complete (outr)……. 2
26 1-513208 Spring, disk ..................................... 3 71 ² 3256-24 Washer, 3/8 SAE ............................ 9
27 1-553039 Sheave, blade drive......................... 3 72 1-603001 Rod, deck support........................... 2
28 1-513016 Bearing, ball ................................... 6 73 1-806332 Roll pin, 1/4 x 1-1/2......................... 2
29 1-323532 Housing, bearing ............................. 3 74 1-613098 Pulley, flat idler ............................... 1
30 1-323528 Spacer, bearing ............................... 3 75 ² 1-603805 Idler ................................................ 1
31 1-633573 Guard, dust ..................................... 3 76 ² 1-513791 Bushing .......................................... 1
32 32120-8 Snap ring......................................... 3 77 ²◆ 1-603494 Spacer ............................................ 1
33 3257-32 Key, woodruff #61 ........................... 4 ∆ 1-633988 Spacer ............................................ 1
34 103-0958 Spindle, outer blade ........................ 2 78 1-603050 Spacer ............................................ 2
35 103-0959 Spindle, center blade....................... 1 79 323-9 Capscrew, 3/8-16 x 1 3/4................. 2
36 1-633482 Blade, notched air foil...................... 3 80❖ 1-414521 Link Assy ........................................ 2
1-613251 Blade, solid air foil ........................... 3 81 1-323533 Spacer, Sheave/Brg........................ 3
1-633485 Blade, low lift ................................... 3 82 103-1305 Asm,complete deck ........................ 1
o 1-633484 Blade, mulching............................... 3 83 103-0865 Washer,blade bolt hvy .................... 3
103-1578 Blade, bahia .................................... 3 84 103-1331 Guard,bearing top............................ 3
37 3219-3 Nut, hex 3/8-24 ................................ 2 85 ✦ 103-2171 Kit,semi-pneumatic wheel replacement 1
38 103-0862 Capscrew,5/8-18x2¾(Gr8) ............... 3 86◆ ² 1-373034 Washer,pivot ................................... 1
² These parts are available in an Idler Pulley Kit (Part No. 1-601806). Each kit contains one item each of the referenced item number.
❖ Link assembly must be assembled to 6.89” (or approx 6 7/8”) length between center of ball joint & center of furthest hole. See diagam on
previous page.
o Requires installation of Micro-Mulch accessory for proper mulching. Mulch kit P/N MK523.
★ FMD523 & FMD603 decks with Serial No. 274,506 & above have semi-pneumatic caster tires. FMD523 & FMD603 decks with Serial No.
274,505 & below have pneumatic caster tires
■ Front caster spacer for semi-pneumatic caster tires can be identified by yellow zinc plating.
m Bushing for semi-pneumatic caster tires can be identified by a groove on the face.
✦ Kit 103-2171 used to install semi-pneumatic casters on machines originally fitted with pneumatic casters. Includes 103-1224 & 103-2169.
Order 2 per machine.
▲ Outer complete cutter housing includes sheave,washer & nut.
Center complete cutter housing includes sheaves,washer, spacer & nut.
Exmark red touch up spray paint - P/N 1-850337
∆ Turf Ranger Serial No. 320,000 & above only. Provided in Turf Ranger bolt bag.
◆
Turf Ranger Serial No. 319,999 & below only. Provided in Turf Ranger bolt bag.
