4
Figure 2. Dimensions – face view
Figure 3. Dimensions – top view
4 x 5/16-inch
(9 mm)
diameter
Display cover can be
rotated as needed
Mounting bracket can
be rotated as needed
2 13/16
(71)
6
(152)
4
(102)
9 3/16
(234)
3 5/8
(92)
12
(305)
11
(279)
inches
(mm)
Approvals tag
5 1/16-inch (129 mm)
clearance for removal of
circuit boards
11 5/16
(288)
6 1/8
(158)
8 11/16
(221)
15 1/2
(394)
inches
(mm)
