10. PIN DESCRIPTION


6

EPSON

S1F77B01 Technical Manual (Rev.1.3)

10. PIN DESCRIPTION


For SOT-23-5

Pin No.

Pin Name

Function

1

DS

Fixed to “LOW”.

2 V

SS

GND

pin.

3 NC

No

connection

4 V

OUT

Voltage detection output pin

5 V

DD

Power input pin


For WCSP

Pin No.

Pin Name

Function

1

DS

Fixed to “LOW”.

2 V

SS

GND

pin.

3 V

DD

Voltage output pin

4 V

OUT

Power detection output pin


11. ABSOLUTE MAXIMUM RATINGS

(T

a

=25°C RL=

∞ unless otherwise specified)

Item Symbol

Rating

Unit

Power voltage

V

DD

-V

SS

7.0

V

Nch open drain output

V

SS

-0.3V to 7.0

Output voltage

CMOS output

V

OUT

V

SS

-0.3V to V

DD

+0.3V

V

Output current

I

OUT

20

mA

SOT23 300

mW

Allowable dissipation

P

D

WCSP 100

mW

Guaranteed operating temperature range

T

opr

-40 to +85

°C

Storage temperature range

T

stg

-40 to +125

°C


Note: To stabilize the IC, insert the decoupling capacitor between V

DD

and V

SS

.
