Specifications — mpa 122

Specifications — MPA 122
1
Extron MPA 122 Mini Power Amplifier • Specifications
Audio
Frequency response ���������������������� 20 Hz to 20 kHz, ±1 dB @ 1 watt output
THD + Noise ���������������������������������� 0�1% @ 1 kHz at nominal level (1 watt, 8 ohm load)
S/N �������������������������������������������������� >74 dB @ 20 Hz to 20 kHz at maximum output (unweighted, with balanced
input)
Stereo channel separation ������������ >55 dB @ 1 kHz, >45 dB @ 20 kHz
CMRR ���������������������������������������������� 80 dB @ 1 kHz, 70 dB @ 20 kHz
Bass adjustment ����������������������������� ±10 dB @ 80 Hz (reference) to 1 kHz (2 dB tolerance)
Treble adjustment �������������������������� ±10 dB @ 10 kHz (reference) to 1 kHz (2 dB tolerance)
Audio input
Number/signal type ��������������������� 1 stereo, balanced/unbalanced input
2 stereo, unbalanced inputs
(The three inputs are individually buffered and mixed together�)
Connectors ������������������������������������� (1) 3�5 mm captive screw connector, 5 pole (main input)
(1) 3�5 mm mini audio jack (tip, ring, sleeve)
1 pair RCA
Impedance �������������������������������������� >18k ohms unbalanced, >24k ohms balanced, DC coupled
Nominal level �������������������������������� +4 dBu (1�23 Vrms) balanced or -10 dBV (316 mVrms) unbalanced
Maximum level
Level pot� at 10 o'clock������ +6 dBV (unbalanced), +16 dBu (balanced) at 1% THD+N
Level pot� at 9 o'clock�������� +17 dBV (unbalanced), +27 dBu (balanced) at 1% THD+N
Input level sensitivity ������������������� -18 dBV from unbalanced input for maximum output (11 watts with a 4 ohm
load and level set to maximum) before clipping
N
0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Audio output
Number/signal type ��������������������� 1 stereo or 2 mono (2 channels total)
Connectors ������������������������������������� (1) 5 mm captive screw connector, 4 pole
Minimum load impedance ���������� 4 ohms
Amplifier type ������������������������������� Improved Class D
Continuous power with a full load and 1% THD
At 4 ohms ��������������������������� 11 watts (rms) per channel
At 8 ohms ��������������������������� 7 watts (rms) per channel
Damping factor ������������������������������ >30 (with a 4 ohm load)
Control/remote — amplifier
Control port ������������������������������������ (1) 3�5 mm captive screw connector, 3 pole
Pin configuration ��������������������������� Pin 1 = +10 VDC, pin 2 = volume/mute (variable voltage), pin 3 = GND
Volume control voltage range ����� 0 V (mute) to 10 V (maximum volume)
General
External power supply ����������������� 100 VAC to 240 VAC, 50/60 Hz, external; to 12 VDC, 3 A (max�), regulated
Power input requirements ����������� 12 VDC, up to 3 A
Temperature/humidity ���������������� Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling ������������������������������������������� Convection, vents on top and sides
Mounting
Rack mount ������������������������ Yes, with optional 1U, 9�5" deep rack shelf (RSU 129, #60-190-01, or RSB 129,
60-604-01); 1U, 6" deep rack shelf (RSU 126, #60-190-10, or RSB 126,
60-604-10); or VersaTools
®
1U, 3�5" deep rack shelf (RSF 123, #60-190-20, or
RSB 123, 60-604-20)
