Page 9 16938-3-0806
APPLIANCE HARDWARE PACKAGE
Figure 5
Appliance Hardware Package Parts List
Part Description Part
Number
Quantity
Supplied
1/4-20 x 1" Phillips Head Bolt R-3188 4
1/4-20 x 3/8" Phillips Head Bolt R-3646 16
1/4-20 x 1/2" Leveling Bolt R-3747 4
No. 10 x 1/2" Hex Washer Head
Screw
R-2737 10
1/4-20 Washer Head Nut R-3185 4
Leg Pad "A" (see Figure 6) CI-008 2
Leg Pad "B" (see Figure 6) CI-009 2
1-1/4" x 1/2" Retaining Tab (see
Figure 8)
CI-007 4
1/4" x 9/32 Washer (Not Shown) R-1150 8
