Z8 Encore!
®
Flash Microcontroller Development Kit
User Manual
22
UM014605-0208
Z8 Encore!® Evaluation Board
33
-RD
Read
Reserved (see note)
34
-WR
Write
Reserved (see note)
35
-RESET
Pushbutton reset
OUT
36
INSTRD
Reserved (see note)
37
-BUSACK
Reserved (see note)
38
-BUSREQ
Reserved (see note)
39
-NMI
Reserved (see note)
40
PHI
Reserved (see note)
41
GND
42
GND
43
PG0
Port G, bit 0
IN/OUT
44
PG1
Port G, bit 1
IN/OUT
45
PG2
Port G, bit 2
IN/OUT
46
PG3
Port G, bit 3
IN/OUT
47
PG4
Port G, bit 4
IN/OUT
48
PG5
Port G, bit 5
IN/OUT
49
PG6
Port G, bit 6
IN/OUT
50
PG7
Port G, bit 7
IN/OUT
51
GND
52
GND
53
-CS0
Reserved (see note)
54
-CS1
Reserved (see note)
55
-CS2
Reserved (see note)
56
-CSx
Reserved (see note)
Table 6. Header J8 (Continued)
Pin No Signal Name Function
Direction Comments
Note: Do not use pins marked Reserved when designing Expansion Modules.
All the signals are driven directly by the MCU.
