Page 22

Z8 Encore!
®
Flash Microcontroller Development Kit
User Manual
18
UM014605-0208
Z8 Encore!® Evaluation Board
Table 5. Header J6
Pin No Signal Name Function
Direction Comments
1
VCC
2
VCC
3
9 V DC
4
9 V DC
5
SCL
I
2
C Clock
OUT
6
ID2
Evaluation Board
ID
OUT
7
SDA
I
2
C Data
IN/OUT
8
ID1
Evaluation Board
ID
OUT
9
GND
10
ID0
Evaluation Board
ID
OUT
11
-MOD_DIS
Modem Disable
OUT
If a shunt is installed the Modem
Function on the evaluation
board is disabled
12
-CON_DIS
Console Disable
OUT
If a shunt is installed the
Console Function on the
evaluation board is disabled
13
-MWAIT
IN
Reserved (see note)
14
GND
15
PE0
Port E, bit 0
IN/OUT
16
17
-CS3
Reserved (see note)
18
19
GND
20
GND
Note: Do not use pins marked Reserved when designing Expansion Modules.
All the signals are driven directly by the MCU.
