Z8 Encore!
®
Flash Microcontroller Development Kit
User Manual
21
UM014605-0208 Z8 Encore!® Evaluation Board
7 PB4 Port B, bit 4 IN ALG4 Analog input
8 PB5 Port B, bit 5 IN ALG5 Analog input
9 PB6 Port B, bit 6 IN ALG6 Analog input
10 PB7 Port B, bit 7 IN ALG7 Analog input
11 GND
12 GND
13 PH0 Port H, bit 0 IN ALG8 Analog input
14 PH1 Port H, bit 1 IN ALG9 Analog input
15 PH2 Port H, bit 2 IN ALG10 Analog input
16 PH3 Port H, bit 3 IN ALG11 Analog input
17 Reserved (see note)
18 Reserved (see note)
19 Reserved (see note)
20 Reserved (see note)
21 GND
22 GND
23 PF0 Port F, bit 0 IN/OUT DTR1
24 PF1 Port F, bit 1 IN/OUT RTS1
25 PF2 Port F, bit 2 IN/OUT DSR1
26 PF3 Port F, bit 3 IN/OUT DCD1
27 PF4 Port F, bit 4 IN/OUT RI1
28 PF5 Port F, bit 5 IN/OUT
29 PF6 Port F, bit 6 IN/OUT
30 PF7 Port F, bit 7 IN/OUT
31 VDD
32 VDD
Table 6. Header J8 (Continued)
Pin No Signal Name Function Direction Comments
Note: Do not use pins marked Reserved when designing Expansion Modules.
All the signals are driven directly by the MCU.
