Page 62
CPU PLL VCore
Use the Page Up and Page Down to scroll through the voltages or select
[Auto] to automatically set the voltage level for the CPU PLL Voltage.
DIMM Voltage
This function defines the voltage level for the DRAM. Use the Page Up and
Page Down keys to select a voltage or select [Auto] to automatically set the
voltage.
DIMM DQ Vref
This function defines the voltage level for the DRAM DQ Vref. Use the
Page Up and Page Down keys to select and set the voltage.
QPI PLL VCore
Use the Page Up and Page Down keys to scroll through the voltages or
select [Auto] to automatically set the voltage level for the QPI PLL voltage.
IOH VCore
This function defines the core voltage level for the Intel IOH chip. Use the
Page Up and Page Down keys to select a voltage or select [Auto] to
automatically set the voltage.
IOH/ICH I/O Voltage
This function defines the core voltage level for the Intel IOH/ICH I/O
voltage. Use the Page Up and Page Down keys to select a voltage or select
[Auto] to automatically set the voltage.
ICH VCore
This function defines the core voltage level for the Intel ICH chip. Use the
Page Up and Page Down keys to select a voltage or select [Auto] to
automatically set the voltage.
PWM Frequency
This function allows you to select the PWM frequency. For the following
options, higher is cleaner, lower is more energy efficient: 800 KHz, 933 KHz,
and 1066 KHz.
CPU Feature
Select
CPU Feature
from the Frequency/Voltage Control menu and press
Enter
to display the CPU Feature menu.
