Extron electronic DA RGBHV User Manual
Da rgbhv series, Analog rgbhv distribution amplifiers

■ 350 MHz (-3dB) RGB video
bandwidth, fully loaded
■ Compatible with RGBHV, RGBS,
RGsB, RsGsBs, component video,
S-video, and composite video
■ Gain/peaking adjustments
■ AC or DC coupling
■ Individually buffered outputs
■ Output muting control
■ Internal international
power supply
■ Rack mountable metal
enclosure
DA RGBHV Series
DISTRIBUTION AMPLIFIERS
ANALOG RGBHV DISTRIBUTION AMPLIFIERS
The Extron DA RGBHV Series of distribution amplifiers split a signal from a high-
resolution source and distribute it to multiple outputs, providing amplification
and enhancement of the signal to maintain signal quality. Models in this series
include the DA2 RGBHV, DA4 RGBHV, and DA6 RGBHV.
