Pa 250, Pa peaking amplifier & sync stripper for rgbhv

INPUT
OU
TPU
T
SOG OU
T
DDSP
SERR
SP
AR
E
50/
60
Hz
100
-24
0V
0.5
A
LEV
EL/
PEA
K
0.8
V 5
0%
UN
ITY
0.9
V 1
00%
BUFF
ERED
LOC
AL
MON
ITOR
OUT
PUT
INPU
T
H. SH
IFT
RGB
109 x
i
VGA
INTE
RFAC
E W
/ADS
P
ID
P
IN
4
ID
P
IN
1
1
0.3
5A
100
-24
0V
50
-60
Hz
OU
TP
UT
2
4
INP
UT
Projector
PC
Up to 1,000' / 305 m
Front
Rear
Extron
RGB 109xi
Interface
Extron
PA 250
Peaking Amplifier
Japan
+81.3.3511.7655
+81.3.3511.7656
FAX
www.extron.com
© 2006 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
uSA
714.491.1500 / 800.633.9876
714.491.1517
FAX
europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050
FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664
FAX
Japan
+81.3.3511.7655
+81.3.3511.7656
FAX
www.extron.com
© 2006 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
uSA
714.491.1500 / 800.633.9876
714.491.1517
FAX
europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050
FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664
FAX
Japan
+81.3.3511.7655
+81.3.3511.7656
FAX
www.extron.com
© 2006 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
uSA
714.491.1500 / 800.633.9876
714.491.1517
FAX
europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050
FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664
FAX
Japan
+81.3.3511.7655
+81.3.3511.7656
FAX
www.extron.com
© 2006 Extron Electronics. All rights reserved.
Pricing and specifications may change without notice.
uSA
714.491.1500 / 800.633.9876
714.491.1517
FAX
europe
+31.33.453.4040 / +800.3987.6673
+31.33.453.4050
FAX
Asia
+65.6383.4400 / +800.7339.8766
+65.6383.4664
FAX
viDeo outPut
Number / Signal type.. . . . . . . . . . . . 1 analog RGBHV, RGBS, RGsB
Connectors.. . . . . . . . . . . . . . . . . . . . . . . . 5 BNC female
Nominal level.. . . . . . . . . . . . . . . . . . . . . 0.7 Vp-p for RGB
Minimum / Maximum levels... . . Analog: 0.3 V to 1.5 Vp-p
Impedance... . . . . . . . . . . . . . . . . . . . . . . . 75 ohms
Return loss.. . . . . . . . . . . . . . . . . . . . . . . . -20 dB @ 5 MHz
DC offset.. . . . . . . . . . . . . . . . . . . . . . . . . . . ±10 mV with input at 0 offset
synC
Input type.. . . . . . . . . . . . . . . . . . . . . . . . . . RGBHV, RGBS, RGsB, RsGsBs
Output type.. . . . . . . . . . . . . . . . . . . . . . . . RGBHV, RGBS, RGsB
Input level
RGBHV, RGBS
.. . . . . . . . . . . . . . . . . . . . . . TTL: 5 Vp-p
RGsB, RsGsBs
.. . . . . . . . . . . . . . . . . . . . . . Analog: 0.3 Vp-p
Output level.. . . . . . . . . . . . . . . . . . . . . . . TTL: 4 V to 5 Vp-p, unterminated
Input impedance.. . . . . . . . . . . . . . . . . 510 ohms
Output impedance.. . . . . . . . . . . . . . . 75 ohms
Max. input voltage.. . . . . . . . . . . . . . . 5 Vp-p
Input sensitivity... . . . . . . . . . . . . . . . . . 0.6 V to 5 Vp-p
Max. propagation delay.. . . . . . . . . 130 ns
Max. Rise / Fall time.. . . . . . . . . . . . . 4 ns
Polarity.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . RGBHV, RGBS: positive or negative (follows input) RGsB, RsGsBs: negative
GenerAL
Power... . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 VAC to 240 VAC, 50/60 Hz, 10 watts, internal, autoswitchable
Temperature / Humidity.. . . . . . . . . Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Rack mount.. . . . . . . . . . . . . . . . . . . . . . . Yes, with optional 1U rack shelf, part #60-190-01 or 60-604-01
Enclosure type.. . . . . . . . . . . . . . . . . . . . Metal
Enclosure dimensions.. . . . . . . . . . . 1.7" H x 8.75" W x 9.4" D (1U high, half rack wide)
4.3 cm H x 22.2 cm W x 23.9 cm D (Depth excludes connectors.)
Product / Shipping weight.. . . . . . 3.0 lbs (1.4 kg) / 5 lbs (3 kg)
Vibration.. . . . . . . . . . . . . . . . . . . . . . . . . . . ISTA 1A in carton (International Safe Transit Association)
Listings / Compliances.. . . . . . . . . . UL, CUL / CE
MTBF.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30,000 hours
Warranty.. . . . . . . . . . . . . . . . . . . . . . . . . . . 3 years parts and labor
D i s t r i b u t i o n A m p l i f i e r s — l i n e D r i v e r s
PA 250
PA Peaking Amplifier & Sync Stripper for RGBHV
feAtures
•
Input: Female BNC connectors
•
Output: Female BNC connectors
•
Compatible with RGBHV, RGBS, RsGsBs, and RGsB
•
250 MHz (-3dB) RGB video bandwidth
•
Variable peaking/sharpness control
•
Variable level control boosts signal voltage
•
Dip switch selectable sync combining and stripping
•
Rack and under-desk mountable
•
1U, half rack width metal enclosure
•
Internal international power supply
DesCriPtion
The Extron
PA 250 is a peaking amplifier capable of driving high resolution RGB video signals
350 feet (105 meters) or more. With an RGB video bandwidth of 250 MHz (-3dB), the PA 250
can be used in applications requiring long cable runs, where signal quality is a primary concern.
The PA 250 also features sync stripping, sync combining, level, and peaking, making it an ideal
all-in-one solution for most signal amplification needs.
The level adjustment allows for compensation of signal level loss that occurs over long cable
runs, while the peaking adjustment compensates for high frequency loss. The level and peaking
controls allow most common, high resolution computer-video signals (30-60 kHz) to travel up to
600 feet (185 meters). The PA 250 can also drive very high resolution computer-video signals
(60-100 kHz) up to 350 feet (105 meters) when using high quality cable such as Extron RG6.
sPeCifiCAtions
viDeo
Gain.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.4 V maximum
Bandwidth.. . . . . . . . . . . . . . . . . . . . . . . . . 250 MHz (-3 dB)
viDeo inPut
Number / Signal type.. . . . . . . . . . . . 1 analog RGBHV, RGBS, RGsB, RsGsBs
Connectors.. . . . . . . . . . . . . . . . . . . . . . . . 5 BNC female
Nominal level.. . . . . . . . . . . . . . . . . . . . . 0.7 Vp-p for RGB
Minimum / Maximum levels... . . Analog: 0.3 V to 1.5 Vp-p with no offset at unity gain
Impedance... . . . . . . . . . . . . . . . . . . . . . . . 75 ohms
Horizontal frequency. . . . . . . . . . . . . 15 kHz to 150 kHz
Vertical frequency.. . . . . . . . . . . . . . . . 40 Hz to 140 Hz
Return loss.. . . . . . . . . . . . . . . . . . . . . . . . <-37 dB @ 5 MHz
moDeL
version DesCriPtion
PArt #
msrP
PA 250
Peaking Amp & Sync Stripper
.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
60-179-01
$
900
oPtionAL ACCessories
moDeL DesCriPtion
PAGe
PArt #
msrP
RSU 129
1U 9.5" Deep Universal Rack Shelf Kit
.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
page 759
60-190-01
$
130
