17
ENGLISH
14. Technical specifications
TKHS 315
2.2 W
Voltage 230 V / 1~50 Hz
Nominal current A 10.6
Fuse protection min. A 1 - 16 (time-lag)
Degree of protection IP 54
Motor speed min -1 2800
Motor capacity
input capacity P
1
power output P
2
kW
kW 2.2 kW S6 40%
1.5 kW S1 100%
Saw blade cutting speed m/s 47
Saw blade diameter (outer) mm 315
Arbor bore mm 30
Depth of cut
with saw blade vertical
at 45
° saw blade tilt
mm
mm 0 ... 85
0 ... 53
Dimensions
length saw table
width saw table
height saw table
height (over all) mm
mm
mm
mm 800
600
850
1150
Weight complete approx. kg 58.2
Sound power level according to DIN 23746*
no-load
when sawing
Sound pressure level according to DIN 31202*
no-load
when sawing
dB (A)
dB (A)
dB (A)
dB (A)
84.0
99.3
74.8
85.0
Ambient temperature range
°c
–10 … +40
Extension cable – min. lead cross section
Length of cable 10 m
Length of cable 25 m mm
2
mm
2
3 x 1.5
3 x 2.5
* The values stated here only indicate the loudness emitted by this machine. Whether the operator is required to wear hearing pro-
tection can not be determined here. This depends on how much noise reaches the ear of the operator. And this, among other
things, depends on the existing ambient conditions (such as other sources of noise near by). Even though it may not be explicitly
required, it is in your own interest to always wear hearing protection when operating this machine.
