Hardware Specifications 5-9
Developer's Guide SR-600
Confidential
Operating clock:
66MHz x 4 /sockets
(input from the chipset via clock generator)
DIMMs that support PC100 (for 100MHz clock) can also
be used.
Usable height:
36mm or less
(maximum 38.23mm in the unbuffered DIMM
specification)
Serial PD (SPD):
Must conform to the Intel PC SPD specifications
(memory information acquisition)
Operating mode:
Must support the self-refreshing mode
5-5 External view of the DIMM
Chip set (82443BX : North bridge)
The Intel chipset 82443BX controls CPU, memory and PCI bus. It also supports AGP bus control
function, but that is not used in SR-600. Combination of this chip set and 82371EB is called
440BX.
≤36mm
1
84
85
168
