6-22 Peripherals/Option Installation Rev.A
Confidential
Installing a Drawer/CRT Board
Follow the steps below to install Drawer/CRT board.
1. Remove the Main cover. (See table 6-15)
2. Slide the motherboard backward. (See table 6-16)
3. Set the motherboard against the wall, then fix it with two screws on the Drawer/CRT board.
Installation is completed.
Two Screws
