5-20 Hardware Specifications Rev.A
Confidential
You can not remove the card that is in operation (see the notes). Turn off the main power to
insert or remove the card.
Also, the top side must be up when inserting the card.
The compact flash card can be used as “Hard Total” in OPOS.
In addition, contact your dealer about the suitable (operation is guaranteed) cards.
Note 1) The compact flash card operating in the True IDE mode is not recognized if it is
removed while the main power is on. Also, the SR-600 does not support the power and a signal
while removing the card; therefore, it might result in crashing the contents of the card.
Note 2) CF card is mounted on the dedicated conversion circuit board. Two types of CF card is
available. One is to attach the card as a Master in HDD space, another one is as a Slave in CD-
ROM space.
LCD/Keyboard unit
General Specifications
The specifications of the DM-LR121T(TFT) and DM-LR121S(DSTN) are shown below.
+CF O O Option Level0 same as
above same as
above
Level1 500mA 500mA
Table 5-7 The differences of Compact Flash and CF+
Operation mode Maximum electric current
PC Card
Memory code PC Card
I/O mode
True IDE mode +5V +3.3V
