Specifications
- 63 -
AUDIO INPUT & OUTPUT CONNECTORS
Analog Audio Inputs 4x stereo single ended/unbalanced pairs
(CD, GAME, Cable/SAT/CBL, BLU-RAY)
2x pairs single ended, unbalanced TV inputs
(RCA)
2x pairs of Balanced XLR (female) inputs
Digital Audio Inputs 8x HDMI
4x coaxial (RCA) 75 Ohms (SPDIF)
3x Optical (TOSLINK)
2x AES/EBU inputs (XLR) 110 Ohms
1x USB 2.0 type B Analog Audio
Analog Outputs 10 balanced XLR male:
Left, Center, Right, Left Surround, Right
Surround, Left Back, Right Back, Left
Auxiliary, Right Auxiliary and Subwoofer
16 single ended (unbalanced) RCA:
Left, Center, Right, Left Surround, Right
Surround, Left Back, Right Back, Left
Auxiliary, Right Auxiliary & Subwoofer, 4 TV
outputs, 2 Zone Two outputs.
Digital Outputs 2x HDMI
1x TOSLINK optical
ELECTRICAL SPECIFICATIONS
Power 120VAC & 230VAC models
Maximum power
consumption 95 Watts
Standby power
consumption <0.5Watt (Ethernet OFF in Standby)
1.5Watt (Ethernet ON in Standby)
DATA & CONTROL PORTS
Trigger Inputs/Outputs One 12V input and 3 programmable trigger
outputs
IR Remote Control Front Panel IR Sensor
1x mini (3mm) phone jack (2 conductor) for
auxiliary Infra-Red control data input
Ethernet 1x Ethernet (RJ45 connector): bilateral data,
software download, etc
RS232 1x 9-pin DB9 Female; for Control and system
feedback
PHYSICAL SPECIFICATIONS
Dimensions 19‖W x 14.25‖D (not including knobs &
connectors or Rack Ears)
5.25‖H (not including rubber feet)
19‖W x 15.38‖D (including knobs &
connectors)
6.25‖H (including rubber feet)
Rack Mount 19‖W standard Rack Mount Width
3RU High without rubber feet
Weight approx 22 lbs (10 kg)
Environmental 50 deg Celsius max
Relative Humidity: 95% maximum without
condensation
