Basic Operation
JBL SYNTHESIS SDP-45
- 15 -
HARDWARE INPUT CONNECTION DEFAULTS
Input HDMI /Video Digital Audio Main Zone Default Zone 2
1 BLU-RAY 1 S/PDIF 1 HDMI Analog
2 SAT/CBL 2 S/PDIF 2 HDMI Analog
3 GAME 3 S/PDIF 3 HDMI Analog
4 MEDIA PLAYER 4 S/PDIF 4 HDMI Analog
5 DVR 5 OPTICAL 1 HDMI Analog
6 TV 6 OPTICAL 2 HDMI Analog
7 CD 7 AES 1 HDMI N/A
8 BALANCED2 8 AES 2 Analog (Balanced) N/A
9 USB See Note N/A USB N/A
These sources do not have any video assigned to their inputs. The last used
video source will remain active when selecting these inputs. To select a video
source first select the active video source and then select the 7.1 or USB
input. If no video is required then do not first select a video source.
10 7.1 Bypass See Note N/A Analog N/A
OUTPUT CONNECTIONS WHEN USED WITH A JBL SYNTHESIS SYSTEM
When used with a JBL Synthesis SDEC-3000, SDEC-4000 or SDEC-4500 Digital EQ/Speaker Processor the system should have been purchased with the
appropriate JBL Synthesis Interconnect Kit, such as S3000IC or S4500XLRIC (or similar). All the interconnect kits come with numbered XLR or RCA
interconnect cables. Use the below chart to connect the 7.1 audio output of the SDP-45 to the correct interconnect cable and input on the SDEC model.
All SDEC models use the same input configuration and numbering.
Cable Number
From Synthesis Interconnect Kit Channel SDEC Input
1 FRONT LEFT A1
2 FRONT RIGHT A2
3 CENTER A3
4 SIDE LEFT A4
5 SIDE RIGHT B1
6 REAR LEFT B2
7 REAR RIGHT B3
8 SUBWOOFER B4
NOTE
