7 PROFIBUS-DP Option Data and I/O Maps
30 YASKAWA ELECTRIC TOBP C730600 23C 1000-Series Option SI-P3/V, SI-P3/T Installation Manual
18
MEMOBUS/Modbus Starting Register
Address
(Low Byte)
18
MEMOBUS/Modbus Starting Register
Address
(Low Byte)
19 MEMOBUS/Modbus Number of Data 19 MEMOBUS/Modbus Number of Data
20 MEMOBUS/Modbus Data 1 (High Byte) 20 MEMOBUS/Modbus Data 1 (High Byte)
21 MEMOBUS/Modbus Data 1 (Low Byte) 21 MEMOBUS/Modbus Data 1 (Low Byte)
22 MEMOBUS/Modbus Data 2 (High Byte) 22 MEMOBUS/Modbus Data 2 (High Byte)
23 MEMOBUS/Modbus Data 2 (Low Byte) 23 MEMOBUS/Modbus Data 2 (Low Byte)
24 MEMOBUS/Modbus Data 3 (High Byte) 24 MEMOBUS/Modbus Data 3 (High Byte)
25 MEMOBUS/Modbus Data 3 (Low Byte) 25 MEMOBUS/Modbus Data 3 (Low Byte)
26 MEMOBUS/Modbus Data 4 (High Byte) 26 MEMOBUS/Modbus Data 4 (High Byte)
27 MEMOBUS/Modbus Data 4 (Low Byte) 27 MEMOBUS/Modbus Data 4 (Low Byte)
28
Reserved
28
Reserved 29 29
30 30
31 Handshaking Register 31 Handshaking Register
<1> To select drive analog output channel for communications, set H4-01 (Multi-Function Analog Output Terminal
AM) to 000 (through-mode).
<2> Drive digital output ON/OFF during communications, set H2-01 (Terminal MA, MB and MC Function Selection
(relay)), H2-02 (Terminal P1 Function Selection (open-collector)), and H2-03 (Terminal P2 Function Selection
(open-collector)) to F (through-mode).
<3> Unit depends on the setting of o1-03 (Digital Operator Display Scaling). Input data is 0 when the drive is set for V/
f Control.
<4> Cannot be used when setting A1-02 (Control Method Selection) to 0 (V/f Control without PG).
<5> Data is displayed in units of either 0.01 A for drives 7.5 kW and smaller, or in units of 0.1 A for drives 11 kW and
larger. This is the same regardless of whether the drive is set for Normal Duty or Heavy Duty operation.
Output (Master Device to Drive) Input (Drive to Master Device)
Byte Description Byte Description
