Page 11
Reattach the rear pivot to the side frame with the bolts
just removed. Tighten.
The wire harness for the three-light identification light
must be repositioned where it comes from the side
frame to the rear pivot to eliminate slack, and sagging
of the wiring.
BUNKS
Make sure the bunks are positioned far enough apart
to give your boat as much stability as possible while
transporting. Position the bunks so they are located
just the outside of a strake that your boat may have.
This will help center your boat and assist when load-
ing. The bunks need be adjusted up high enough to
keep the keel from resting on the center pads. A mini-
mum of one to two inches clearance is desirable.
FRONT BUNK SUPPORT
The front bunks should be adjusted either in or out so
that the bunk will continue to run just to the outside
of the strake of the boat. Adjust the bunks up so that
there is approximately 1-2 inches clearance between
the keel of the boat and the center cross member
pad.
WINCH POST
Once all other adjustments are complete the winch
post can be adjusted. Slide the winch post base back-
ward on the tongue until the bow roller comes in con-
tact with the boat.
This bow roller needs to be positioned directly above
the boat bow eye to prevent your boat from moving
forward in the event of a sudden stop. It can be moved
up or down by removing the back bolt that mounts the
winch head to the base. When this bolt is removed,
the head can be rotated up or down to reach the de-
sired height required to fit your boat. Once in this posi-
tion, align the closest pair of holes in the brackets and
reinsert the bolt just removed. Tighten.
Attach the winch strap and crank winch tight. Attach
the bow eye safety chain into the bow eye of the boat
as well. This is just another level of protection to keep
your boat and trailer together as one unit.
Adjustments are now complete. Double check your
boat for fit. If the desired fit has been achieved, tighten
all fasteners that may have either been left loose or
have been loosened to do the adjusting.
Note: All nuts and bolts must be tightened before tow-
ing. The law requires that the white ground wire on
both the tongue wire harness and vehicle harness be
properly grounded to respective trailer and vehicle
frames.
Recheck all fasteners on the complete trailer to make
sure they are all tight and ready for towing. All fasten-
ers should be periodically checked before towing.
See your ShoreLand’r Owner’s Guide for further
technical information regarding your trailer and its
components.
