76
Chapter 3
LCD Module Disassembly Process
IMPORTANT:The outside housing and color may vary from the mass produced model.
LCD Module Disassembly Flowchart
Screw List
Step
Screw
Quantity
Part No.
LCD Bezel
M2.5*5
4
86.AT902.002
Inverter Board
M2.5*5
1
86.AT902.002
Camera Module
M2*L3
1
86.AT902.003
LCD Panel
M2.5*5
2
86.AT902.002
LCD Brackets
M2*L3
8
86.AT902.003
Remove
Inverter Board
Remove
LCD Panel
Remove
LCD Bezel
Remove
LCD FPC Cable
Remove
Camera Module
Remove LCD
Panel from Main
Unit before
proceeding
Remove
LCD Brackets
Remove
Antennas
Remove
MIC Cable
