LCD screen controls

(Prefinished models with LCD)

If you have a double DishDrawer®, each drawer has its own control panel and can run
independently of the other.

Power Button

The

button turns the DishDrawer®

on or off. Opening the drawer will automatically turn the

DishDrawer®

on for 30 seconds. To end a wash program in mid cycle, press the

button. Any

water in the DishDrawer®

will be pumped out.

Start/Pause Button

The

button starts a wash program. Press the

button to pause or restart the

DishDrawer®

during a wash program. When paused, wait for three beeps before opening the

drawer. Forcing the drawer open while in mid cycle may cause damage or injury.

Delay Start

The

button also sets the Delay Start feature which can delay the start of a wash program

from 1 to 12 hours. This feature also satisfies Shabbat requirements if the Auto Power option is
disabled (see Option Adjustment).

To activate Delay Start

Press and hold the

button until the delay symbol

appears on the electronic display.

Continue holding the

button down until the desired delay time has been reached.

The DishDrawer® will start once the delay time has elapsed and the drawer is closed.

To cancel Delay Start

Press the

button.

Lock Button

(optional)

The

button activates/deactivates the Keylock or the Childlock functions.

Keylock

The Keylock feature disables all the buttons on the control panel.
To activate, press and hold the

button until you hear one beep (3 seconds). The

symbol

appears in the electronic display when the Keylock feature is activated.

Wash program progress
symbol

Time remaining
(Delay Start)

Power button

Electronic display
(LCD screen)

Start/Pause button

Lock button

Delay Start symbol
