FEATURES AND CONTROLS
Instrument Cluster
Diagnostic Display Code Definitions
Diagnostic Codes
Component Condition SPN FMI
Fan Relay Driver
Circuit Voltage Above Normal, Or Shorted To High Source 1071 3
Voltage Below Normal, Or Shorted To Low Source 1071 4
Current Below Normal Or Open Circuit 1071 5
Ignition Coil Primary
Driver 1 (Front)
(MAG) Voltage Above Normal, Or Shorted To High Source 1268 3
Voltage Below Normal, Or Shorted To Low Source 1268 4
Current Below Normal Or Open Circuit 1268 5
Fuel Pump Driver
Circuit Voltage Above Normal, Or Shorted To High Source 1347 3
Voltage Below Normal, Or Shorted To Low Source 1347 4
Current Below Normal Or Open Circuit 1347 5
Oxygen Sensor 1 Data Erratic, Intermittent Or Incorrect 3056 2
Voltage Above Normal, Or Shorted To High Source 3056 3
Voltage Below Normal, Or Shorted To Low Source 3056 4
Bad Intelligent Device Or Component 3056 12
ECU Output Supply
Voltage 1 Data Valid But Above Normal Operational Range - Most
Severe Level 3597 0
Data Valid But Below Normal Operational Range - Most
Severe Level 3597 1
Voltage Above Normal, Or Shorted To High Source 3597 3
Voltage Below Normal, Or Shorted To Low Source 3597 4
Data Valid But Above Normal Operating Range - Moderately
Severe Level 3597 16
Data Valid But Below Normal Operating Range - Moderately
Severe Level 3597 18
ECU Output Supply
Voltage 2 Data Valid But Above Normal Operational Range - Most
Severe Level 3598 0
Data Valid But Below Normal Operational Range - Most
Severe Level 3598 1
Voltage Above Normal, Or Shorted To High Source 3598 3
Voltage Below Normal, Or Shorted To Low Source 3598 4
Data Valid But Above Normal Operating Range - Moderately
Severe Level 3598 16
Data Valid But Below Normal Operating Range - Moderately
Severe Level 3598 18
ECU Output Supply
Voltage 3 Data Valid But Above Normal Operational Range - Most
Severe Level 3599 0
Data Valid But Below Normal Operational Range - Most
Severe Level 3599 1
Voltage Above Normal, Or Shorted To High Source 3599 3
Voltage Below Normal, Or Shorted To Low Source 3599 4
Data Valid But Above Normal Operating Range - Moderately
Severe Level 3599 16
Data Valid But Below Normal Operating Range - Moderately
Severe Level 3599 18
ETC Accelerator
Position Sensor
Outputs 1 & 2
Correlation Data Erratic, Intermittent Or Incorrect 65613 2
