133
SPECIFICATIONS
Clutching (325)
Please see your dealer for clutching specifications.
Clutching (570)
SPORTSMAN ACE / SPORTSMAN ACE 570
Lubrication System Wet Sump
Engine Oil PS-4 5W-50
Driving System Type Automatic POLARIS Variable Transmission
Shift Type Side Lever (H/L/N/R/P)
Gear Reduction - Low 28.84:1
Gear Reduction - Reverse 25.83:1
Gear Reduction - High 9.65:1
Drive Ratio - Front 2.989:1
Tire Size - Front 25x8-12
Tire Size - Rear 25x10-12
Tire Pressure Front: 7 psi (48 KPa)
Rear: 7 psi (48 KPa)
Brakes, Park Park in Transmission
Brakes, Front/Rear Foot Activated, 4-wheel hydraulic disc
Headlights 2 single beam, 55W halogen
Taillights 2 single beam, 6W
Brake Lights 2 single beam, 27W
Instrument Cluster LCD
Auxiliary DC Outlet 12V
Altitude Shift
Weight
Drive Clutch
Spring
Driven Clutch
Spring
Meters
(Feet)
0-1500
(0-5000)
25-52
PN 5632409
Black 35-240
PN 7043594
Black/Almond
PN 3235088
1500-3700
(5000-12000)
25-48
PN 5632408
Black 35-240
PN 7043594
Black/Almond
PN 3235088
