BDS-6464 Rev. 1
1
1 General
The BDS-6464 is a 64x64 serial digital video router with vertical interval switching. This state of the art
router provides maximum quality with a data rate of up to 540 Mbps and automatic cable equalising on
all inputs. High performance circuits in SMD technology assure undiminished signal quality. The BDS-
6464 is well suited for all demanding routing tasks in digital studio and broadcast environments. The
built-in RS-232 interface allows the user to control the router via the Triton Router Control System, with
its many operational features. The control bus technology allows linking the unit with the BAS-6464 or
BES-6464 to create an AFV router. One or several Triton remote control panels can control the BDS-
6464 as well. Another unique feature of the Triton 64x64 series is the possibility to reconfigure the router
via the configuration switch on the back plane to create several formats of routers:
64x64 Serial Digital Video 1 layer
32x32 Serial Digital Video 2 layer
21x21 Serial Digital Video 3 layer
16x16 Serial Digital Video 4 layer
1.1 Specifications
Data rate: 143Mbit/s - 540Mbit/s
VIT input: Comp. Video 1Vpp, 300mV sync, looped 75ohms
Number of inputs: 64 terminated
Equalisation: Automatic up to 300m ( Belden 8281 )
Number of outputs: 64
Impedance: 75 ohms
Return-loss: > 18dB (10MHz-270MHz)
Signal level: 800mV fixed, 75 ohms load
Ris/fall time: typ. 700ps
Connector: BNC
RS-232 interface: 19200 baud
AC power: External power supply 100 - 260 VAC
DC power: +5V, molex 2-pin connector
Dimensions: 483 x 264 x 120 mm (19”, 6RU)
