BDS-6464 Rev. 1
15
5.4 Power up mode
Switch 8 on the configuration switch SW A defines the power up mode. The BDS-6464 router provides
two modes for powering up the system.
Mode 1 switches all outputs to input 1.
Mode 2 switches all outputs according to the buffered information in the routers processor system.
The power up reset can be switched according to the following pattern:
- means switch down
* means switch up
Switch
8 Power Up Reset
- Mode
2
* Mode 1
Default is Mode 2.
5.5 Select VIT field
The DIP-switch SW B at the back has the following meaning:
Switches 1-7 are not used,
Switch 8 selects the VIT mode
- means switch down
* means switch up
Switch
8 VIT mode
- VIT on any field
* VIT on ODD fields only
Default mode is VIT on any field.
6 Connecting video signals to the BDS-6464
The BDS-6464 router offers standard 75 ohms BNC connectors for video in- and outputs. All video
inputs are terminated with 75 ohms.
