BDS-6464 Rev. 1
3
2 Power connection
Do not connect mains to the desktop power supply before connecting the power supply to the
router.
Connect the Molex 2-pin power connector from the desktop power supply to the main unit. Tighten the
screws to assure a proper contact. To connect mains to the desktop power supply you need a mains cord
with IEC 320 connector. BDS-6464 uses the desktop power model AC +5V / 110W.
Upon customer request, BDS-6464 can also be delivered with DC +5V / 130W, which may be fed by a
36 - 72 VDC mains power source. A Frame mounted power supply solution is also available.
Please refer to the latest Triton Product Catalogue for power supply types, or call Thomson Grass Valley
for this information.
If any third party power supply is used the BDS-6464 router requires +5V DC with a minimum current of
16.0A. The following pin-out is used on the Molex 2-pin power connector, both on the router and the
power cable:
A1 A2
A1 (Female) 0 V
A2 (Male) +5 V
