BDS-6464

Rev. 1


10

5.2 Router

mode

The BDS-6464 router allows switching in different modes. You can choose among:

64x64

Serial Digital Video 1 layer

32x32

Serial Digital Video 2 layer

21x21

Serial Digital Video 3 layer

16x16

Serial Digital Video 4 layer


Switch 5 - 6 on the configuration switch SW A set the router’s mode. The Triton Router Control System
software must be configured according to the mode chosen on the router.

The modes can be switched according to the following pattern:

-

means switch down

*

means switch up


Switch

5 6 Mode


-

-

64x64 Serial Digital Video 1 layer

-

*

32x32 Serial Digital Video 2 layer

*

-

21x21 Serial Digital Video 3 layer

*

*

16x16 Serial Digital Video 4 layer



Default mode is 64x64 Serial Digital Video 1 layer.

Serial Digital Video 1 layer

SDV Signal Input

SDV Signal Output

1 1 1 1
2 2 2 2
3 3 3 3
4 4 4 4
5 5 5 5
6 6 6 6
7 7 7 7
8 8 8 8
9 9 9 9
10

10

10

10

11

11

11

11

12

12

12

12

13

13

13

13

14

14

14

14

15

15

15

15

16

16

16

16

17 17 17 17
18 18 18 18
