HDS-1616 Rev. 0
1
1 General
The HDS-1616 is a 16x16 high definition serial digital video router with universal wideband technology
to allow simultaneous switching of digital video signals from 143Mbps up to 1.5Gbps. HDS-1616 has
automatic cable equalizing on all inputs and re-clocking with automatic standard selection on all outputs.
Vertical interval switching is provided on a video reference input with PAL/NTSC colour black. The
HDS-1616 is well suited for all demanding routing tasks in digital studio and broadcast environments.
The built-in RS-232 interface allows the user to control the router via the Triton Router Control System,
with its many operational features. The control bus technology allows linking the unit with the BAS-1616
or BES-1616 to create an AFV router. One or several Triton remote control panels can control the
HDS-1616 as well. Another unique feature of the Triton 16x16 series is the possibility to reconfigure the
router via the configuration switch on the back plane to create several formats of routers:
16x16 Serial Digital Video 1 layer
8x8 Serial Digital Video 2 layer
5x5 Serial Digital Video 3 layer
4x4 Serial Digital Video 4 layer
1.1 Specifications
Data rate: 143Mbps – 1.5Gbps
VIT input: Comp. Video 1Vpp, 300mV sync, 75 ohms
Number of inputs: 16 terminated
Equalisation: Automatic up to 100m @ 1.5G ( Belden 1694A )
Number of outputs: 16
Re-clocking: On outputs, auto standard select
Impedance: 75 ohms
Return-loss: > 15dB (5MHz-1.5GHz)
Signal level: 800mV ±10%
Connector: BNC
AC power: External power supply 100 - 260 VAC
DC power: +5V, connector DB9 male
Dimensions: 483 x 88 x 35 mm (19”, 2RU)
