HDS-1616 Rev. 0
9
Switch 5 6 Mode
- - 16x16 Serial Digital Video 1 layer
- * 8x8 Serial Digital Video 2 layer
* - 5x5 Serial Digital Video 3 layer
* * 4x4 Serial Digital Video 4 layer
Default mode is 16x16 Serial Digital Video 1 layer.
Serial Digital Video 1 layer
SDV Signal Input SDV Signal Output
1 1 1 1
2 2 2 2
3 3 3 3
4 4 4 4
5 5 5 5
6 6 6 6
7 7 7 7
8 8 8 8
9 9 9 9
10
10 10 10
11 11 11 11
12 12 12 12
13 13 13 13
14 14 14 14
15 15 15 15
16 16 16 16
Serial Digital Video 2 layer
SDV layer 1 Input SDV layer 1 Output
1 1 1 1
2 2 2 2
3 3 3 3
4 4 4 4
5 5 5 5
6 6 6 6
7 7 7 7
8 8 8 8
SDV layer 2 Input
SDV layer 2 Output
1 9 1 9
2 10
2 10
3 11 3 11
