5.4 Power up mode
Switch 8 on the configuration switch defines the power up mode. The HDS-1616 router provides two
modes for powering up the system.
Mode 1 switches all outputs to input 1.
Mode 2 switches all outputs according to the buffered information in the routers processor system.
The power up reset can be switched according to the following pattern:
- means switch down
* means switch up
Switch
8 Power Up Reset
- Mode
2
* Mode 1
Default is Mode 2.
6 Connecting video signals to the HDS-1616
The HDS-1616 router offers standard 75 ohms BNC connectors for video in- and outputs. All video
inputs are terminated with 75 ohms.
