8
Hardware and Block Diagrams
Available Models
Available Models
The TelePort 3G is available in a variety of standard models. The following list covers the
models available at the time of publication.
The TelePort 3G comes in five models. The three Transceiver types have identical front
panels and vary only on the rear panel depending on their Fiber Optic I/O configuration.
The Transmitter and Receiver types have their own unique models.
Part Number Type
SDI/DATA
Transmit SDI/DATA
Receive Number of
Fibers
TP3-MNPP-W16 Transceiver 8 8 1
TP3-MNPP-W8W8 Transceiver 8 8 2
TP3-QUPP-W16 Transceiver 8 8 1
TP3-MNQU-W16 Transmitter 16 X 1
