Remove the Product Covers

Profile LAN Upgrade Installation

13

Figure 1. PDR 100 Showing Attaching Screws for the Top Covers

Circuit board cover: It
cannot be removed until
cover for disk drives and
fans has been removed.

Disk Drive and fan cover:
It must be removed first.

9041-13
