Analog Composite Output Installation
8 Analog Composite Output Installation
Table 1. Circuit Board Identification for Figure 6
Slot Number Assembly Number Circuit Board Name
J1 A10 486 Processor
J2 A20 VGA
J3 A21 LAN
J4 A16 Decoder
J5 A15 Analog Composite Input
J6 A19 Audio Adapter (I/O)
J7
J8 A16 Decoder
J9 A15 Analog Composite Input
J10 A19 Audio Adapter (I/O)
J11 A17 Analog Composite Output
J12 A19 Audio Adapter (I/O)
J13 A19 Audio Adapter (I/O)
J14 A12 Master Disk Recorder
J15 A13 Slave Disk Recorder
J16 A11 Reference Genlock
