Analog Composite Output Installation
1
Analog Composite Output Installation
Kit Description
This product modification kit adds a circuit board to provide two NTSC analog
composite output channels. Refer to Configuration section in the PDR 100
User manual for more information.
Kit Parts List
• One Analog Composite Output board
• One Audio Clock Routing cable
• One EMI suppression gasket
• One set of PDR100 option labels
• PDR0F3V Installation instructions
