KayakDD Installation Planning Guide 27
Specifications
Table 6. Power
KayakDD-1 Frame
Line voltage
100V-240V AC +/-10% autorange, power factor corrected (48V / 5A
DC Input for ext. redundancy)
Line frequency 50/60Hz +/- 5%
Power consumption max. 150W (max. 200W with 48V DC supply for panel)
Leakage current < 2.5 mA
RAMRecorder buffer voltage: 6..8V DC approx. 150 mA.
DC-OUT for control panel 48V DC, max 1.6A
KayakDD-1 Control Panel
DC-IN 48V DC In, max 1.3A
Power consumption max. 50W
KayakDD-2 Frame
Line voltage
100V-240V AC +/-10% autorange, power factor corrected (48V / 5A
DC Input for ext. redundancy)
Line frequency 50/60Hz +/- 5%
Power consumption max. 250W (max. 310W with 48V DC supply for panel)
Leakage current < 2 mA
RAMRecorder buffer voltage: . 6…8V DC approx. 150 mA
DC-OUT for control panel 48V DC, max 1.6A
KayakDD-2 Control Panel
DC-IN 48V DC In, max 1.3A
Power consumption max. 60W
KDD-PSU Frame
Line voltage 100V-240V AC +/-10%, power factor corrected
Line frequency 50/60Hz +/- 5%
Power consumption max. 375W
Leakage current < 2 mA at 250V AC
DC-OUT 2x 48V DC, total 6A max
EXT BATT IN 12V … 24V, 0.5A
RAM Recorder buffer voltage: 7V DC, max 300mA. (Only with ext. battery input or AC In)
