Rack mounting – Grass Valley KayakDD Installation Planning Guide User Manual
Page 20
20
KayakDD Installation Planning Guide
KayakDD-2 Installation
Rack Mounting
Figure 15. KayakDD-2 Rack Mounting
CAUTION
Mounting using only the front rack angles is permitted for fixed installations.
Additional support, like slide rails, is required for mobile applications (flight
case, OB van).
Slide rails.
Recommended for mobil applications.
Not part of delivery.
Air
Flow
Air Flow
