Sentriant AG200 Hardware Installation Guide 13
3 Installing the Sentriant AG200 Appliance
This chapter includes the following sections:
● Overview on page 13
● Required Tools and Equipment on page 13
● Attaching the Rack-Mount Brackets on page 13
● Installing the Sentriant AG Appliance in a Rack on page 14
● Connecting Power on page 15
● Connecting Cables on page 15
Overview
The Sentriant AG200 appliance fits into a standard 19-inch (48.26 cm) rack.
Before you install the Sentriant AG appliance, carefully read the information in Appendix A, “Safety
Information.”
Required Tools and Equipment
You need the following items to install the Sentriant AG appliance:
● Mounting hardware provided with the Sentriant appliance
■ Two rack-mount brackets
■ Eight bracket-mounting screws
● Phillips screwdriver for attaching rack-mount brackets
● Rack mounting hardware appropriate to your equipment rack
● Screwdriver appropriate for the mounting hardware used with your equipment rack
NOTE
Rack-mounting hardware is not included with the Sentriant AG appliance. Use mounting screws appropriate to your
equipment rack.
Attaching the Rack-Mount Brackets
To attach the rack-mount brackets:
1 Place a rack-mount bracket along one side of the Sentriant AG appliance and align it with the
mounting holes in the chassis (see
Figure 3 ).
2 Insert and tighten the provided Phillips screws to secure the bracket to the Sentriant AG appliance.
