GUIDE TO INSTALLATION AND OPERATION
KMV-3901/3911 |
5
2.3.4 HD-SDI Monitoring Output Connectors
There are two HD-SDI monitoring outputs: one associated with Head 1, and one with Head 2 if enabled. The
HD-SDI output resolution depends on the current resolution at the corresponding HDMI output, and, in the
case of a 1080-line resolution, on the scan format (interlaced, progressive) configured in XEdit for this output
head.
HDMI output resolution
HD-SDI output (interlaced) HD-SDI output (progressive)
1280 × 720 50Hz
No output
720p 50Hz
1280 × 720 59.94Hz
No output
720p 59.94Hz
1920 × 1080 50Hz
1080i 50Hz
1080p 50Hz
1920 × 1080 59.94Hz
1080i 59.94Hz
1080p 59.94Hz
Any other HDMI resolutions
No output
No output
2.4 Front Card Edge
2.4.1 USB Connector
This USB connector is accessible when the front panel of the Densité frame is open.
The USB connector is used for the following tasks:
•
Upgrading the Kaleido-X Software and KMV-3901/3911 firmware, by using a USB key prepared with the
appropriate upgrade package. Refer to the Kaleido-X Release Notes for details.
•
Controlling some features on the monitor wall, by using a mouse (e.g. showing or hiding the monitor wall
dashboard, dismissing the confirmation message that appears at the end of the upgrade process). Refer
to the Kaleido-X User’s Manual for details.
Note: The KMV-3901/3911 does not support USB hubs. Only one USB device (USB key or mouse) can be
connected at a time. If an externally powered USB hub is connected to the KMV-3901/3911, then a mouse
connected to the hub will not work.
2.4.2 Bridge Connectors
The bridge connectors are accessible when the front panel of the Densité frame is open.
They are used to interconnect two adjacent KMV-3901/3911 cards by using a cascade bridge (Miranda
part no. KMV-3901-8XN-BRIDGE). Refer to the KMV-3901/3911 Cascade Step-by-Step Configuration guide,
available on the Kaleido-X DVD, for detailed instructions on setting up a cascade system.
