44 K2 ASI Media Client User Manual June 10, 2008
Chapter 5 Recording
6. Click the record list icon in the bottom-left corner of the overlay.
The Record List view is displayed. It is empty.
The name of the selected service corresponds to the title of the Record list view. In
our example, the service name is Service 1 and so is the record list's. When several
services are selected, the title is MPTS.
The top two lines describe the current recording event ( red line), when present, and
the next event to be recorded ( orange line). The record list is displayed in
minimized mode.
Use the toggle buttons to maximize it vertically and horizontally.
NOTE: The thumbnail is the one corresponding to the selected service that is used to
display the list.
Record List Views
Reaching the Lists
To reach the Lists view, there must be at least one record list created.
Weekly record list means that the event is defined not only for this week but also for
all the subsequent weeks. Event will be recorded this week; the week after, it will be
destroyed to be recorded again.
To reach the Lists view, click the button located under the services or double-click
on the record list in the ASI boards and connectors output view. If the view is already
open, it pops to the front of the screen.
The top two lines describe the event that is currently being recorded ( red line) and the
next event to be recorded ( orange line). The status of each event is indicated to the left
of each line. Each line has a decreasing counter indicating the time left for the event
to record (
red line) or the time remaining before it begins ( orange line) when no event
is recording.
